Product Details:
|
| Warranty: | 1 Year | Applicable Industries: | Printing Company, Packaging Product Company, Printing Shops, Other |
|---|---|---|---|
| Showroom Location: | Canada, United States, France, Germany, Peru, Mexico, Russia, Kazakhstan, Japan, Australia | Marketing Type: | Spot Products |
| Type: | Roller | Use: | ROLAND |
| Printing Type: | High Speed Printing | Product Name: | Rubber Roller |
| Usage: | Finished Product Installation | Model: | ROLAND |
| Use For: | Offset Printer | MOQ: | 1 Piece |
| Feature: | 100% Compatible | Quality: | Excellent 100% Tested |
| Shipping Method: | DHL Fedex TNT EMS UPS Sea Freight Land Transportation | Color: | Black |
| Port: | Shenzhen Yantian Port，Guangzhou， Hong Kong | Material: | EPDM |
| Highlight: | UV Printing neoprene rubber roller,ROLAND neoprene rubber roller,ROLAND printing press ink rollers |
||
Installation method of UV rubber roller
1, clean the impurities on both ends of the new rubber roller, and then select bearings that meet the design requirements in terms of specifications and models. Apply lubricating oil to each mating surface, and correctly and evenly hammer the special bearing sleeve until the bearing is installed in place. Do not apply force directly on the bearings and knock them randomly to prevent damage to the bearings before use.
2. Ensure the lubrication of each bearing and shaft seat of the rubber roller. Before installing the rubber roller, the outer surface of the bearings at both ends of the rubber roller and the rubber roller bearing sleeve, bracket, etc. on the machine should be coated with lubricating grease to minimize the rotation, impact, and friction caused by the back and forth movement of the ink roller, and to reduce the wear on both sides of the rubber roller shaft sleeve and shaft seat.
3. New Ink Roller Adaptation Program: Before installing the entire set of new glue rollers and preparing to print with UV ink, the ink rollers must be run with UV transparent ink or UV ink for 2-3 hours to fully adapt to the UV ink. After cleaning with UV washing machine water, the UV printing program can be carried out. If the above procedure is not followed, some UV ink may become hard and accumulate on the surface of the ink roller, resulting in uneven ink application, heat generation, and difficulty in cleaning. The ink roller is also prone to wear and tear. If using a new ink roller
XINBAO high-end rubber wheels have bright colors from the appearance, with a delicate and smooth colloidal surface and strong adhesion between the glue and the core. The size of rubber rollers does not change significantly at different temperatures and can adapt to high temperature and humidity environments or harsh cold and dry climate conditions. (ROLAND)
The quality and condition of the rubber drum are crucial for Heidelberg printing machines to achieve sustained and stable high-quality printing. Regular cleaning and maintenance, as well as repackaging when rubber is worn, are necessary maintenance measures.
parameters
| Place of Origin | Guangdong, China |
| Brand Name | XIN BAO |
| Model Number | XINBAO- |
| Material | EPDM |
| Color | Black |
| Product name | ROLAND |
| Application | Offset Printing Machine |
| Size | Standard |
| Hardness | Shore38°~40° |
| Item | ROLAND |
| Type | Metal Shaft Rubber Roller |
| Features | Pro INK |
| Surface finish | Ra0.8 |
Dongguan xinbao rubber roller co., LTD. specializes in the production of printing machine
rubber roller(HEIDELBERG, ROLAND, KOMORI, KBA, MITSUBISHI, SHINOHARA, RYOBI, etc.), UV special, UV/ ordinary dual-purpose rubber roller processing; UV/ oil roller, polishing machine bottom gun, trademark machine rubber roller, peritoneum roller, folding machine rubber roller, paper roller and other rubber products
The company has complete testing equipment, 31 years of experience in cots processing and strong technical force, excellent quality, reasonable price, products have been widely recognized and trusted by users, and can meet the constantly developing economic and social needs.
We sincerely welcome the business friends in the printing industry and look forward to establishing friendly and cooperative business relations with you and achieving the win-win goal.
Q1: Are you manufacturer or trading company?
A: We are manufacturer!
Q2: How to get a quotation fast?
A: Provide details of material requirements, hardness, size, quantity or photos. Detailed drawings are best.
Q3: What about the lead time for production?
A: usually 10-25 days, but it also depends on the quantity of the order and the type of product.
Q4: How is your factory doing in terms of quality control?
A: quality comes first. Xinbao attaches great importance to quality control from the beginning to the end of production. Every product has to be carefully inspected before it's packed and shipped.
